ALL BILLS ARE REJECTED
Bill path
obstructed/dirty
Apply power.
Check for cause, correct,
reset Outlet Breaker.
List Errors to determine cause. Refer to
Programming for Error explanations.
All Bills are
rejected.
Main Power
OFF/Disconnected.
Outlet Breaker
tripped.
Check MDB Harness & connections.
Machine Out
of Service.
Fill Coin Tubes.
Coin Mech low
on Coins.
Clean & reset Gate.
Clear / clean path.
Gate partially
open.
MDB Harness.
Reset Switches.
Replace Validator.
Replace Validator.
Defective VMC.
Replace VMC.
Defective
Validator.
Should have a heartbeat on/off pattern.
VMC D5 Red
Diagnostic Light
Incompatible
Validator.
Wrong Option
Switch settings.
Should be On with Service Door
Open.
VMC D6 Yellow
Diagnostic Light
