Loom Label Component Side/Port Switch Port
White LH Side 12 SSU1 A 1 Eth SW0 4
White LH Side 13 SSU2 A 1 Eth SW0 6
White LH Side 14 SSU3 A 1 Eth SW0 8
White LH Side 15 SSU4 A 1 Eth SW0 1
White LH Side 16 LHS PDU 1 Eth SW0 12
White LH Side 17 SSU5 A 1 Eth SW0 3
White LH Side 18 Unused Unused
White LH Side 19 Unused Unused
White LH Side 20 MMU / AMMU A 1 Eth SW0 10
White LH Side 21 SMU A 1 Eth SW0 9
White LH Side 22 RAS/KVM LHS Eth SW0 11
Blue RH Side 23 SSU0 B 2 Eth SW1 24
Blue RH Side 24 SSU1 B 2 Eth SW1 22
Blue RH Side 25 SSU2 B 2 Eth SW1 20
Blue RH Side 26 SSU3 B 2 Eth SW1 18
Blue RH Side 27 SSU4 B 2 Eth SW1 23
Blue RH Side 28 RHS PDU 1 Eth SW1 12
Blue RH Side 29 SSU5 B 2 Eth SW1 21
Blue RH Side 30
Blue RH Side 31
Blue RH Side 32 MMU / AMMU B 2 Eth SW1 16
Blue RH Side 33 SMU B 2 Eth SW1 15
Blue RH Side 34 RAS/KVM RHS Eth SW1 11
Blue RH Side 35 Fabric SW 1 1 (on rear of
switch)
Eth SW1 14
White RH Side 36 SSU0 B 1 Eth SW0 24
White RH Side 37 SSU1 B 1 Eth SW0 22
White RH Side 38 SSU2 B 1 Eth SW0 20
White RH Side 39 SSU3 B 1 Eth SW0 18
White RH Side 40 SSU4 B 1 Eth SW0 23
White RH Side 41 SSU5 B 1 Eth SW0 21
White RH Side 42 Unused Unused
White RH Side 43 Unused Unused
