Cray ClusterStor L300 - Page 104

Loom Label Component Side/Port Switch Port
White RH Side 44 MMU / AMMU B 1 Eth SW0 16
White RH Side 45 SMU B 1 Eth SW0 15
White RH Side 46 Fabric SW 0 1 (on rear of
switch)
Eth SW0 14
Table 11. Lustre 24-Port Management Network Interconnect List - Storage Rack with Optional MMU
Loom Label Component Side/Port Switch Port
Blue LH Side 1 SSU0 A 2 Eth SW1 2
Blue LH Side 2 SSU1 A 2 Eth SW1 4
Blue LH Side 3 SSU2 A 2 Eth SW1 6
Blue LH Side 4 SSU3 A 2 Eth SW1 8
Blue LH Side 5 SSU4 A 2 Eth SW1 1
Blue LH Side 6 SSU5 A 2 Eth SW1 3
Blue LH Side 7 Unused Unused
Blue LH Side 8 Unused Unused
Blue LH Side 9 SSU6 A 2 Eth SW1 10
Blue LH Side 10 Optional
Additional MMU
A 2 Eth SW1 9
White LH Side 11 SSU0 A 1 Eth SW0 2
White LH Side 12 SSU1 A 1 Eth SW0 4
White LH Side 13 SSU2 A 1 Eth SW0 6
White LH Side 14 SSU3 A 1 Eth SW0 8
White LH Side 15 SSU4 A 1 Eth SW0 1
White LH Side 16 LHS PDU 1 Eth SW0 12
White LH Side 17 SSU5 A 1 Eth SW0 3
White LH Side 18 Unused Unused Eth SW0 5
White LH Side 19 Unused Unused Eth SW0 7
White LH Side 20 SSU6 A 1 Eth SW0 10
White LH Side 21 Optional
Additional MMU
A 1 Eth SW0 9
White LH Side 22 RAS/KVM LHS Eth SW0 11
Blue RH Side 23 SSU0 B 2 Eth SW1 24
Blue RH Side 24 SSU1 B 2 Eth SW1 22
Blue RH Side 25 SSU2 B 2 Eth SW1 20
