Loom Label Component Side/Port Switch Port
Blue RH Side 26 SSU3 B 2 Eth SW1 18
Blue RH Side 27 SSU4 B 2 Eth SW1 23
Blue RH Side 28 RHS PDU 1 Eth SW1 12
Blue RH Side 29 SSU5 B 2 Eth SW1 21
Blue RH Side 30 Unused Unused Eth SW1 19
Blue RH Side 31 Unused Unused Eth SW1 17
Blue RH Side 32 SSU6 B 2 Eth SW1 16
Blue RH Side 33 Optional
Additional MMU
B 2 Eth SW1 15
Blue RH Side 34 RAS/KVM RHS Eth SW1 11
Blue RH Side 35 Fabric SW 1 1 (on rear of
switch)
Eth SW1 14
White RH Side 36 SSU0 B 1 Eth SW0 24
White RH Side 37 SSU1 B 1 Eth SW0 22
White RH Side 38 SSU2 B 1 Eth SW0 20
White RH Side 39 SSU3 B 1 Eth SW0 18
White RH Side 40 SSU4 B 1 Eth SW0 23
White RH Side 41 SSU5 B 1 Eth SW0 21
White RH Side 42 Unused Unused Eth SW0 19
White RH Side 43 Unused Unused Eth SW0 17
White RH Side 44 SSU6 B 1 Eth SW0 16
White RH Side 45 Optional
Additional MMU
B 1 Eth SW0 15
White RH Side 46 Fabric SW 0 1 (on rear of
switch)
Eth SW0 14
Table 12. Lustre 48-Port Management Network Interconnect List - Base Rack
Loom Label Component Side/Port Switch Port
Blue LH Side 1 SSU0 A 2 Eth SW1 26
Blue LH Side 2 SSU1 A 2 Eth SW1 28
Blue LH Side 3 SSU2 A 2 Eth SW1 30
Blue LH Side 4 SSU3 A 2 Eth SW1 32
Blue LH Side 5 SSU4 A 2 Eth SW1 25
Blue LH Side 6 SSU5 A 2 Eth SW1 27
Reference
105
