Loom Label Component Side/Port Switch Port
Blue LH Side 7 Unused Unused
Blue LH Side 8 Unused Unused
Blue LH Side 9 MMU / AMMU A 2 Eth SW1 34
Blue LH Side 10 SMU A 2 Eth SW1 33
White LH Side 11 SSU0 A 1 Eth SW0 26
White LH Side 12 SSU1 A 1 Eth SW0 28
White LH Side 13 SSU2 A 1 Eth SW0 30
White LH Side 14 SSU3 A 1 Eth SW0 32
White LH Side 15 SSU4 A 1 Eth SW0 25
White LH Side 16 LHS PDU 1 Eth SW0 36
White LH Side 17 SSU5 A 1 Eth SW0 27
White LH Side 18 Unused Unused
White LH Side 19 Unused Unused
White LH Side 20 MMU / AMMU A 1 Eth SW0 34
White LH Side 21 SMU A 1 Eth SW0 33
White LH Side 22 RAS/KVM LHS Eth SW0 35
Blue RH Side 23 SSU0 B 2 Eth SW1 48
Blue RH Side 24 SSU1 B 2 Eth SW1 46
Blue RH Side 25 SSU2 B 2 Eth SW1 44
Blue RH Side 26 SSU3 B 2 Eth SW1 42
Blue RH Side 27 SSU4 B 2 Eth SW1 47
Blue RH Side 28 RHS PDU 1 Eth SW1 36
Blue RH Side 29 SSU5 B 2 Eth SW1 45
Blue RH Side 30 Unused Unused Eth SW1 43
Blue RH Side 31 Unused Unused Eth SW1 41
Blue RH Side 32 MMU / AMMU B 2 Eth SW1 40
Blue RH Side 33 SMU B 2 Eth SW1 39
Blue RH Side 34 RAS/KVM RHS Eth SW1 35
Blue RH Side 35 Fabric SW 1 1 Eth SW1 38
White RH Side 36 SSU0 B 1 Eth SW0 48
White RH Side 37 SSU1 B 1 Eth SW0 46
White RH Side 38 SSU2 B 1 Eth SW0 44
White RH Side 39 SSU3 B 1 Eth SW0 42
