Loom Label Component Side/Port Switch Port
Blue RH Side 10 SSU1 B I IB SW1 34
Blue RH Side 11 SSU2 B I IB SW1 32
Blue RH Side 12 SSU3 B I IB SW1 30
Blue RH Side 13 SSU4 B I IB SW1 28
Blue RH Side 14 SSU5 B I IB SW1 26
Blue RH Side 15 MMU / AMMU B I / I IB SW1 24
Blue RH Side 16 SMU B I IB SW1 22
Table 14. Lustre InfiniBand EDR Data Network Interconnect List - Storage Rack with Optional MMU
Loom Label Component Side/Port Switch Port
White LH Side 1 SSU0 A I IB SW0 2
White LH Side 2 SSU1 A I IB SW0 4
White LH Side 3 SSU2 A I IB SW0 6
White LH Side 4 SSU3 A I IB SW0 8
White LH Side 5 SSU4 A I IB SW0 10
White LH Side 6 SSU5 A I IB SW0 12
White LH Side 7 SSU6 A I IB SW0 14
White LH Side 8 Optional
Additional MMU
B I IB SW0 16
Blue RH Side 9 SSU0 B I IB SW1 36
Blue RH Side 10 SSU1 B I IB SW1 34
Blue RH Side 11 SSU2 B I IB SW1 32
Blue RH Side 12 SSU3 B I IB SW1 30
Blue RH Side 13 SSU4 B I IB SW1 28
Blue RH Side 14 SSU5 B I IB SW1 26
Blue RH Side 15 SSU6 B I IB SW1 24
Blue RH Side 16 Optional
Additional MMU
B I IB SW1 22
Table 15. Lustre Omni-Path Data Network Interconnect List - Base Rack (24-port)
Loom Label Component Side/Port Switch Port
White LH Side 1 SSU0 A 1 OPA SW0 1
White LH Side 2 SSU1 A 1 OPA SW0 2
Reference
108
