Loom Label Component Side/Port Switch Port
White LH Side 3 SSU2 A 1 OPA SW0 3
White LH Side 4 SSU3 A 1 OPA SW0 4
White LH Side 5 SSU4 A 1 OPA SW0 5
White LH Side 6 SSU5 A 1 OPA SW0 6
White LH Side 7 MMU / AMMU A 1 / 1 OPA SW0 7
White LH Side 8 SMU A 1 OPA SW0 8
Blue RH Side 9 SSU0 B 1 OPA SW1 16
Blue RH Side 10 SSU1 B 1 OPA SW1 15
Blue RH Side 11 SSU2 B 1 OPA SW1 14
Blue RH Side 12 SSU3 B 1 OPA SW1 13
Blue RH Side 13 SSU4 B 1 OPA SW1 12
Blue RH Side 14 SSU5 B 1 OPA SW1 11
Blue RH Side 15 MMU / AMMU B 1 / 1 OPA SW1 10
Blue RH Side 16 SMU B 1 OPA SW1 9
Table 16. Lustre Omni-Path Data Network Interconnect List - Storage Rack with Optional MMU (24-port)
Loom Label Component Side/Port Switch Port
White LH Side 1 SSU0 A 1 OPA SW0 1
White LH Side 2 SSU1 A 1 OPA SW0 2
White LH Side 3 SSU2 A 1 OPA SW0 3
White LH Side 4 SSU3 A 1 OPA SW0 4
White LH Side 5 SSU4 A 1 OPA SW0 5
White LH Side 6 SSU5 A 1 OPA SW0 6
White LH Side 7 SSU6 A 1 OPA SW0 7
White LH Side 8 Optional
Additional MMU
B 1 OPA SW0 8
Blue RH Side 9 SSU0 B 1 OPA SW1 16
Blue RH Side 10 SSU1 B 1 OPA SW1 15
Blue RH Side 11 SSU2 B 1 OPA SW1 14
Blue RH Side 12 SSU3 B 1 OPA SW1 13
Blue RH Side 13 SSU4 B 1 OPA SW1 12
Blue RH Side 14 SSU5 B 1 OPA SW1 11
Blue RH Side 15 SSU6 B 1 OPA SW1 10
Reference
