3
4.Device Installation
4.3 Z-axis Cable Drag Chain Installation
A.
Insert the mainboard adapter cable into the appropriate interface and assemble the Z-axis cable drag chain at this end.
B. Complete the assembly of the other end of the Z-axis cable drag chain.
06
Figure A
Figure B
3
Z-axis Cable Drag Chain

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality CR-M4 and is the answer not in the manual?

Creality CR-M4 Specifications

General IconGeneral
Build Volume450 x 450 x 470 mm
Filament Diameter1.75 mm
Max. Nozzle Temperature300°C
Number of Extruders1
Frame MaterialAluminum Alloy
Printing TechnologyFDM (Fused Deposition Modeling)
Nozzle Diameter0.4 mm
ConnectivityUSB, Wi-Fi
Supported MaterialsPLA, ABS, PETG, TPU
Power Supply50/60Hz
Print Speed30 - 120 mm/s
