4
Display screen
4.5 Display screen Installation
A. Assemble the display screen frame with three M4*20 screws.
B.
C.
Align the pins on the back of the display screen with the punched holes in the display screen frame and insert it, then slide it downwards to fasten it.
Insert the display screen cable into the appropriate interface and snap the cable into the buckle.
4.Device Installation
08
21
21
Hexagon Socket Button
Head Screw M4*20 × 3
Figure A
Figure B
5
Display Screen Frame

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Creality CR-M4 and is the answer not in the manual?

Creality CR-M4 Specifications

General IconGeneral
Build Volume450 x 450 x 470 mm
Filament Diameter1.75 mm
Max. Nozzle Temperature300°C
Number of Extruders1
Frame MaterialAluminum Alloy
Printing TechnologyFDM (Fused Deposition Modeling)
Nozzle Diameter0.4 mm
ConnectivityUSB, Wi-Fi
Supported MaterialsPLA, ABS, PETG, TPU
Power Supply50/60Hz
Print Speed30 - 120 mm/s
