Crestron CP3N Reference Guide

Reference Guide – DOC. 7150B 3-Series Control Systems • 61
5. Click Choose, and then select the CSV file created in step 1.
6. Click Claim to claim all of the devices listed in the file. A message
indicating the claim status of each device is displayed.
NOTE: If an error message is displayed stating that a device does not
exist, connect that device to a network that has access to the Internet,
wait 15 minutes, and then try again.
7. Click X to close the dialog box. The hostnames of the claimed devices
appear in the device tree under the group
Unassociated Devices.
Unassociated Devices
The devices may now be managed and assigned to a group.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
