8-18 Periodic Maintenance and Adjustment
[1]．Trough
3. Remove the radiator cap.
[1]．the radiator cap.
4. Remove the coolant reservoir cap.
5. Disconnect the hose on the coolant
reservoir side, and then drain the coolant
from the coolant reservoir.
[1].Reservoir drain hose
6. After draining the coolant, thoroughly
flush the cooling system with clean tap
water.
7. Replace the coolant drain bolt washer if it
is damaged. Install the coolant drain bolt,
To Next Page
