Control Functions 4-15
down the pedal will stop the ATV. This brake
pedal controls the entire brake system. It
applies brakes to all the wheels.
1. Foot brake pedal
Parking brake – Park position lever
The parking brake lever is located on the left
handlebar. Holding the lever thoroughly tight
will stop the ATV. Holding the lever down can
maintain the ATV brake in the on position,
which will also activate the park position
indicator on the display. If necessary, the
brake can be used as emergency brake.
1. Parking latch (if equipped) 2. Parking handlebar
