Control Functions 4-3
CAUTION:
The engine may overheat if the ATV is
overloaded. If this happens, reduce the
load to specification.
Headlight indicator “ ”
When the headlights are on, this indicator will
light.
Position light indicator“
”
When the headlight is on, this indicator will
light.
Emergency flashers “
”
When the emergency flasher is on, this
indicator will light.
Speedometer Unit
1. RPM indicator
2. Odometer/trip meter/Eng. hours & Clock adjustment
3. Left turn signal light
4. Speed indicator
5. Right turn signal light
6. Miles per hour/Kilometers per hour selector button
7. 2WD / 4WD indicator light
8. Differential Lock indicator light
Speedometer unit functions:
a speedometer (which shows the speed)
