4-4 Control Functions
an odometer (which shows the total
distance covered)
a trip meter (which can be cleared and
then show any new distances traveled)
an RPM indicator (which shows the
revolutions per minute of the engine)
a clock
an EFI fault code indicator (which shows
the fault code diagnosed by EFI )
Odometer and trip meter modes
On the display panel there are two large
buttons, one located on the left side and one
on the right side. Quickly toggle the button on
the left side can switch the display from the
odometer to the trip meter, and then to the
hours meter; then it starts the cycle over.
The odometer displays the total distance
traveled by the ATV. The trip meter can
record distances up to 999.9 miles for specific
trips. To reset the trip meter, press the left
button to switch to small mileage (Trip), then
press the right button for a long time to reset.
The trip meter can also be used to estimate
the distance that can be traveled with a full
tank of fuel. This information will enable you to
judge the fuel consumption.
To switch the miles to kilometers on the
display, press the right side button.
Clock time adjustment
Press the left button and hold for three
seconds and the clock goes into the hour ‘set’
mode.
