4-2 Control Functions
Indicator and Warning Lights
1. Position Light
2. High beam indicator
3. Park position indicator “P”
4. Neutral indicator “N”
5. Gear display
6. Emergency flashers indicator
7. Coolant temperature gauge
Low-gear range indicator “F”
This indicator light comes on when the drive
select lever is in the “F” position.
Neutral indicator“
N”
This indicator comes on when the drive
select lever is in the “N” position.
Reverse indicator“
R”
This indicator comes on when the drive
select lever is in the “R”position.
Park indicator “
P”
This indicator light comes on when the
mechanical parking brake is applied.
Coolant temperature warning indicator“
”
When the coolant temperature reaches a
specified level, this light comes on indicating
the coolant temperature is too hot. If the light
comes on during operation, stop the engine
as soon as it is safe to do so and allow the
engine to cool down for about 15 minutes.
