4-6 Control Functions
the stability and safety of the ATV operation.
CAUTION:
When the selector is set to 4WD “DIFF.
LOCK”, the right 4WD symbol front axle will
have an ‘X’ in the middle. When riding on
smooth flat surfaces you should unlock the
differential and press in the yellow and the
gray buttons to the 2WD unlocked position.
There should be no symbols showing in
either the left or right 4WD indicators.
CAUTION:
If the display indicators flash or the
speedometer does not show the speed while
the ATV is in motion, consult a dealer to check
the speed sensor and circuits.
Fault code indicator
When the EFI encounters faults, the ECU will
send the fault code to the instrument display,
and it will flash on the clock.
If there are more than one fault code, they will
be shown in rolling sequence. When fault
codes are present, press the clock button to
check time. Then after five seconds, the fault
code returns again. Only when the fault is
fixed, the time could show automatically.
The description for the fault codes are shown
in Chapter 11 of this manual.
Fuel level indicator
The fuel level display will indicate the fuel
volume. When the fuel is getting low the fuel
pump indicator will flash.
