Control Functions 4-5
1. Press the right button to set the hour.
2. Press the left button again and the clock
goes into the minute ‘set’ mode.
3. Press the right button to set the minutes.
4. Press the left button again and the clock
will exit the ‘set’ mode.
Four-wheel drive indicator “ ”/ “ ”
There are two 4WD indicators on the display
panel. The left 4WD indicator has a blinking
circle on the front axle when the grey and
yellow 4WD selector buttons are pressed in
indicating the “4WD” function has been
activated. This position also indicates that the
4WD is NOT locked. This allows the wheels
on the left and right sides to rotate at different
speeds to accommodate turning.
Differential gear lock indicator
“
DIFF-LOCK
”
The right 4WD symbol will show an ‘X’ over
the center of the front axle when the lever is
moved to the right and the yellow differential
gear lock button is set to the " " out position,
which means the differential is not operational
and is locked. When riding an ATV on muddy
and slippery roads or when climbing a steep
hill, make sure the 4WD lock indicator is on.
When riding on a flat road at a comparatively
high speed, adjust the settings to
“2WD/UNLOCK” and there are no symbols in
either of the 4WD indicators.
Riding an ATV while the differential is
functioning and is NOT locked, may improve
