Periodic Maintenance and Adjustment 8-23
[1]．Air filter case check hose
1. Remove the cover panels on the right
side of the fuel tank.
2. Remove the air filter from the ATV.
3. Loosen the fasteners. Remove the air
filter case cover.
[1]. Air filter case [2]. Fasteners [3]. Air filter element
4. Remove the air filter element cover.
5. Remove the air filter element from its
case.
6. Wash the air filter element gently but
thoroughly in solvent.
WARNING
Never clean the filter element with
gasoline, clean it with professional
cleaning solvent.
