PARTS INFORMATION MICRO-TEMP
®
LT, Model 749
OPERATION AND TECHNICAL MANUAL
Page 62 of 75
SECTION 6. PARTS INFORMATION
6-1. INTRODUCTION
This section outlines information for ordering, shipping and replacing parts of the MICRO-TEMP
®
LT unit, Model 749. Identification of parts and components are shown in Figures (6-2), (6-4) and
(6-6). The numbers in Figures (6-1), (6-3), and (6-5) correspond to the numbers in the
accompanying parts list in Figures (6-2), (6-4), and (6-6). Figure (6-7) diagrams the functional
operation of the unit and Figure (6-8) lists the MICRO-TEMP
®
LT System equipment and
accessories.
6-2. ORDERING INFORMATION FOR REPLACEMENT PARTS
Replacement parts are available directly from CSZ or through our authorized MICRO-TEMP
®
LT
system dealer. When ordering parts, specify the replacement part number as well as the serial
number of your unit located on the specification label on the back of the unit. There is no minimum
order requirement for replacement parts. Section (6-3) outlines the recommended replacement
parts inventory.
It is strongly recommended that all parts be replaced with parts purchased from CSZ. Use of
other parts could void the warranty on the unit and possibly damage the unit.
6-3. RECOMMENDED REPLACEMENT PARTS INVENTORY
Part Number
Qty.
Description
91090
1
Pump (100V)
91091
1
Pump (115V)
91092
1
Pump (230-240V)
65160
1
Heater (100V)
65161
1
Heater (115V)
65162
1
Heater (230/240V)
41002
1
Thermistor
91162
1 pkg of 5
63 mAmp Fuse for Control Board (230/240V)
91163
1 pkg of 5
GDC-1 Fuse for Power Switch (230/240V)
91164
1 pkg of 5
125mAmp Fuse for Control Board
(100/115V)
91165
1 pkg of 5
2 Amp Fuse for Power Switch (100/115V)
