PARTS INFORMATION MICRO-TEMP
®
LT, Model 749
OPERATION AND TECHNICAL MANUAL
Page 70 of 75
SECTION 7. SPECIFICATIONS AND CERTIFICATIONS OF THE MICRO-
TEMP
®
LT
MICRO-TEMP
®
LT MODEL 749 FEATURES
CLASSIFICATION
Equipment is Class I.
Equipment is Type BF.
SAFETY SYSTEM
Maximum High Control Setting:
42°C (107°F)
High Limit Safety:
44°C 0.5°C (111°F 1°F)
Minimum Low Control Setting:
20°C (68°F )
High Limit Failure Indicator:
Audible & Visual
Low Water Indicator:
Visual
Power Fail Indicator:
Audible & Visual
Tilt Switch Indicator:
Audible & Visual
>1°C Over Temp Indicator:
Audible & Visual
Water Temperature Sensor Fault
Indicator: Audible & Visual
PHYSICAL
Dimensions: 9.8"W x 8.2"D x 9.1"H
(24.9cm W x 20.8cm D x
23.1cm H)
Weight: 9.0lbs (4.1kg) – empty with
power cord attached.
Hose Length: Approx. 8 ft (2.4m.)
Cabinet Construction:
Casing is made of Lexan 923 plastic. Single
reservoir. Built-in handle. Bottom air discharge.
Four suction cups.
Ambient Temperature (during use):
20°C 0.5°C (68°F 1°F) to 35°C 0.5°C
(95°F 1°F).
Maximum Contact Surface Temperature:
41°C (105.8°F)
ELECTRICAL SYSTEM
Electrical Characteristics:
100 V: 90VAC – 110 VAC, 1.7 amp, 50/60 Hz
115 V: 99VAC – 127 VAC, 1.7 amp, 60 Hz
230/240V: 207VAC – 264VAC
Power Cord: Detachable, approx. 10 feet in
length, includes a cord strap, and a 3 conductor,
16/18 AWG Hospital grade plug.
Leakage Current: Under 300 µa
(100V/115V); Under 500 µa (230V).
Circuit Breaker: Fuse In Power Switch,
Mains Supply Isolation: Two-Pole Mains Switch
THERMAL SYSTEM
Heater: 150 Watts
NOTE: The contact surface temperature shall
heat up from 23±2C to 37C in approximately
15 minutes.
CIRCULATING SYSTEM
Single Reservoir, 0.24 gallon (0.9 liters) total
capacity of distilled water. Permanently
attached hose. Error proof, quick-disconnect
fittings. Minimum flow rate of 15 GPH (56.8
L/hr).
