PARTS INFORMATION MICRO-TEMP

LT, Model 749

OPERATION AND TECHNICAL MANUAL

Page 69 of 75

ACCESSORIES - PADS

MAXI-THERM

Single-Patient Use Pads

273 Infant Size (12” x 18”)

MAXI-THERM

LITE Single-Patient Use Pads

870 L.T.T. Pad (25” x 4”)

871 L.T.T. Pad (25”x 17.25”)

872 L.T.T. Pad (25” x 19”)

873 Infant Size (12.5” x 18”)

PlastiPad

Reusable Blankets

193 CPC Infant Size (12” x 18”) with CPC Connector

Gelli-Roll

Pads

193P Infant Size (13” x 19.75”)

Other Available Accessories

UNV LP Universal Stand

MT-081 Adapter Plate

737-HDU Dual Pad Connecting Hose

TF100 Dual-Matic (Temperature Tester, Flow Meter)

Figure 6-8 Micro-Temp

LT System Accessories
