Chapter 8. Configuration Commands
8-11
WAN
The router supports 8 PVC, private virtual circuit, and so you can setup eight WANs; WAN1 to
WAN8. Move the cursor “ >> “ to wan and press enter. To setup WAN1, type 1.
----------------------------------------------------------------------
Command: setup wan <1~8>
Message: Please input the following information.
Interface number <1~8>: 1
------------------------------ ----------------------------------------
>>
protocol Link type protocol
address IP address and subnet mask
vpi_vci Configure VPI/VCI value
encap Configure encapsulation type
qos Configure VC QoS
isp Configure account name, password and idl e time
ip_type Configure IP type in PPPoA and PPPoE
list WAN interface configuration
There are four types of connection protocols, IPoA, EoA, PPPoA and PPPoE, which may or may
not be supported by your ISP. For PPPoA and PPPoE, you do not need to setup any IP
addresses and subnet masks. However, a valid username/password must be provided by your
ISP for the PPP authentication.
There is a unique VPI and VCI value for Internet connection supported by ISP. The range of VPI
is from 0 to 255 and VCI from 0 to 65535.
There are two types of encapsulation methods; VC-Mux and LLC.
You can setup virtual circuit quality of service, VC QoS, using the qos command. There are two
QoS classes; UBR and CBR. The peak cell rate can be configured from 64kbps to 2400kbps.
>>
class Configure QoS class
pcr Configure peak cell rate (kbps)
scr Configure sustainable cell rate (kbps)
mbs Configure max. burst size (cell)
The ISP command can configure the account name, password and idle times. Idle times are from
0 minute to 300 minutes.
You can review the WAN interface configuration via the list command.
