Chapter 8. Configuration Commands
8-13
VLAN
Virtual LAN (VLAN) is defined as a group of devices on one or more LANs that are configured so
that they can communicate as if they were attached to the same wire, when in fact they are
located on a number of different LAN segments. Because VLAN is based on logical instead of
physical connections, it is extremely flexible.
The specification of VLAN function is as follow:
1. The unit supports up to 8 active VLANs with shared VLAN learning (SVL) bridge out of
4096 possible VLANs specified in IEEE 802.1Q.
2. Each port always belongs to a default VLAN with its port VID (PVID) as an untagged
member. Also, a port can belong to multiple VLANs and be tagged members of these
VLANs.
3. A port must not be a tagged member of its default VLAN.
4. If a non-tagged or null-VID tagged packet is received, it will be assigned with the default
PVID of the ingress port.
5. If the packet is tagged with non-null VID, the VID in the tag will be used.
6. The look up process starts with VLAN look up to determine whether the VID is valid. If the
VID is not valid, the packet will be dropped and its address will not be learned. If the VID is
valid, the VID, destination address, and source address lookups are performed.
7. The VID and destination address lookup determines the forwarding ports. If it fails, the
packet will be broadcasted to all members of the VLAN, except the ingress port.
8. Frames are sent out tagged or untagged depend on if the egress port is a tagged or
untagged member of the VLAN that frames belong to.
9. If VID and source address look up fails, the source address will be learned.
You can setup the Virtual LAN (VLAN) parameters with the vlan command. The router supports
the implementation of VLAN-to-PVC only for bridge mode operation, i.e., the VLAN spreads over
both the COE and CPE sides, where there is no layer 3 routing involved. The unit supports up to
8 active VLANs with shared VLAN learning (SVL) bridge out of 4096 possible VLANs specified in
IEEE 802.1Q.
Move the cursor “ >> “ to vlan and press enter.
>>
mode Trigger virtual LAN function
modify Modify virtual LAN rule
pvid Modify port default ID
link_mode Modify port link type
list Show VLAN configuration
