Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194170-47320 PLATE 1

2 CY-194555-47340 PLATE (A) 1

3 CY-194555-47350 PLATE 1

4 CY-198220-47380 SHAFT, CONTROL LEVER 1

5 CY-194208-47420 BAR, CONTROL 1

6 CY-198220-47430 SHAFT 1

7 CY-194170-47440 PLATE, FRICTION 1

8 CY-194208-47440 LEVER, FEED BACK 2

9 CY-198220-47490 GUIDE 1

10 CY-194550-47530 ADJUSTER 1

11 CY-194208-47550 BAR 1

12 CY-198220-47560 ROD, FEED BACK 1

13 CY-198220-47570 BAR 1

14 CY-1A8160-47610 LEVER, LIFT ARM 1

15 CY-194151-47760 WASHER 12 4

16 CY-194208-47860 HOLDER 2

17 CY-22117-080000 WASHER 8 2

18 CY-22137-100000 WASHER 10,POLISHED 2

19 CY-22137-100000 WASHER 10,POLISHED 1

20 CY-22137-120000 WASHER 12,POLISHED 1

21 CY-22272-000060 CIRCLIP E- 6 2

22 CY-22272-000070 CIRCLIP E- 7 1

23 CY-22351-040016 SPRING PIN 4X16 1

24 CY-22351-050020 SPRING PIN 5X20 2

25 CY-22417-300200 COTTER PIN 3.0X20 1

26 CY-22522-030130 WOODRUFF KEY 3X13 1

27 CY-24311-000150 O-RING 1A P-15.0 1

28 CY-24311-000150 O-RING 1A P-15.0 1

29 CY-26013-080162 BOLT W/WASHER M8X16 2

30 CY-26013-080162 BOLT W/WASHER M8X16 2

31 CY-26116-080554 BOLT 8*55 2

32 CY-26716-080002 NUT M 8 4

33 CY-26716-100002 NUT 10 2

34 CY-198220-47370 KNOB 1

FIG. 77. HYDRAULIC CONTROL

121
