Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194990-22130 NUT W/WASHER 6 1

2 CY-198220-52180 RELAY, STARTER 1

3 CY-198220-52180 RELAY, STARTER 1

4 CY-1A8160-52510 SUPPORT,RELAY 1

5 CY-1A6780-57200 FLUSHER UNIT 1

6 CY-194151-57210 SPACER 1

7 CY-1K1140-82500 RELAY(ACM13211M01 1

8 CY-1K1140-82500 RELAY(ACM13211M01 1

9 CY-1K1140-82500 RELAY(ACM13211M01 1

10 CY-22137-060000 WASHER 6, POLISHED 1

11 CY-26106-060162 BOLT M 6X 16 PLATED 1

12 CY-26106-060162 BOLT M 6X 16 PLATED 1

13 CY-26106-080122 BOLT M 8X 12 PLATED 2

14 CY-26347-060002 U-NUT, 6 1

135

FIG. 89. RELAY
