Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194180-12471 NUT, CASTLE 2
2 CY-1A8160-17400 CYLINDER ASSY 1
3 CY-1A7335-17310 CAP, CYLINDER 1
4 CY-1A7335-17410 ROD ASSY 1
5 CY-1A7335-17500 ROCK NUT 1
6 CY-1A7335-17520 CIRCLIP 120 1
7 CY-1A7335-17530 CIRCLIP 120 1
8 CY-1A7335-17550 SEAL KIT 1
9 CY-1A7335-17750 PISTON 1
10 CY-22417-400250 COTTER PIN 4.0X25 2
58
FIG. 26. POWER STEERING CYLINDER
Copyright 2007 Cub Cadet Yanmar LLC
