Cub Cadet Yanmar Ex32002

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194150-45320 SPRING, RELIEF VALVE 1
2 CY-198220-45350 COLLAR 1
3 CY-198220-45370 PLUG, SAFETY VALVE 1
4 CY-198220-46400 SHIM PACK 1
5 CY-194640-46410 SEAT, SAFETY VALVE 1
6 CY-194640-46420 POPPET, SAFETY VALVE 1
7 CY-22351-060028 SPRING PIN 6X28 1
8 CY-24311-000120 O-RING 1A P 12.0 1
9 CY-24311-000180 O-RING 1A P-18.0 1
116
FIG. 75. SAFETY VALVE
Copyright 2007 Cub Cadet Yanmar LLC
