Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-194447-13490 CAP W/DIPSTICK 1

2 CY-194274-13570 SPRING WASHER 10 12

3 CY-1A8160-13600 FRONT AXLE CASE CMP 1

4 CY-194850-13660 BUSHING 2

5 CY-1A8160-13650 CARRIER, DIFFERENTIAL 1

6 CY-1A8160-13660 GASKET, CARRIER 1

7 CY-194850-13690 NIPPLE M6F, GREASE 1

8 CY-22190-080000 SEAL WASHER 8(BOLT) 1

9 CY-22252-000621 CIRCRIP 62 1

10 CY-22252-000680 CIRCLIP 68 2

11 CY-22312-080160 PARALLEL PIN 8X 16 2

12 CY-24311-000180 O-RING 1A P-18.0 1

13 CY-24321-000800 O-RING 1A G-80.0 2

14 CY-24421-254208 SEAL TC25 42 08, OIL 1

15 CY-26108-100302 BOLT M10X 30 PLATED 12

16 CY-26108-100302 BOLT M10X 30 PLATED 8

17 CY-26116-080122 BOLT M 8X 12 PLATED 1

FIG. 16. FRONT AXLE CASE
