Cub Cadet Yanmar Ex32002

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-22240 SHAFT, RELEASE 1
2 CY-198220-22310 YOKE, CLUTCH RELEASE 1
3 CY-1A8160-27400 PLATE, CRUISE ASSY 1
4 CY-24550-020200 BUSH 20X20,DRY 1
5 CY-22272-000150 CIRCLIP E-15 1
6 CY-22351-035040 SPRING PIN 3.5X40 1
7 CY-22351-060040 SPRING PIN 6X40 1
66
FIG. 33. CLUTCH RELEASE
Copyright 2007 Cub Cadet Yanmar LLC
