Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194515-13220 SPACER 25X42X14 1
2 CY-1A8160-13230 SHIM PIN, CENTER 1
3 CY-1A7450-13230 SHIM 4
4 CY-1A8160-13270 SHIM 0.25 4
5 CY-1A8160-13240 PIN, CENTER 1
6 CY-22157-140000 WASHER 14 1
7 CY-26116-140302 BOLT M14X 30 PLATED 1
8 CY-26108-120252 BOLT 12* 25 4
9 CY-22217-140000 SPRING WASHER 14 1
41
FIG. 10. CENTER PIN
Copyright 2007 Cub Cadet Yanmar LLC
