Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-198230-33500 GEAR, FINAL DRIVE 2
2 CY-194440-32580 COLLAR 45X55X20 2
3 CY-198230-34050 SHAFT, REAR AXLE 1
4 CY-198230-34101 SHAFT, REAR AXLE 1
5 CY-198230-34111 SHAFT, REAR AXLE 1
6 CY-22242-000400 CIRCLIP 40 2
7 CY-22242-000450 CIRCLIP 45 4
8 CY-24101-060094 BALL BEARING 2
9 CY-24101-062084 BALL BEARING 2
97
FIG. 60. FINAL GEAR & REAR AXLE SHAFT
Copyright 2007 Cub Cadet Yanmar LLC
