Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A8160-56100 PANEL, INSTRUMENT 1

2 CY-198220-53170 SCREW 8

3 CY-1A8160-56110 METER ASSY 1

4 CY-1A7335-56120 PANEL 1

5 CY-198220-56130 PACKING 1

6 CY-198220-56140 GLASS 1

7 CY-198220-56150 RETAINER 1

8 CY-198220-56160 PACKING 1

9 CY-1A8160-56200 CASE ASSY 1

10 CY-1A8160-56210 HARNESS, WIRING 1

11 CY-198220-56220 LAMP 3

12 CY-124617-91920 BULB 3

13 CY-198220-56230 SCREW 6

14 CY-26022-030062 SCREW M 3X 6 2

15 CY-194555-56890 GROMMET 15 2

16 CY-194275-56900 CABLE, HOUR-METER 1

17 CY-194145-61651 NUT, M5 4

18 CY-194940-61790 SCREW 5X16 4

19 CY-26589-060162 SCREW M6, BINDING 2

134

FIG. 88. INSTRUMENT PANEL
