Ex Series Ex3200

REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-1A7780-53200 HEADLIGHT ASSY, L.H. 1

2 CY-1A7000-53230 WIRE ASSY, LEAD 1

3 CY-198448-53320 BULB 12V45/45W 1

4 CY-1A7260-53251 LENS, SIDE L.H 1

5 CY-1A7260-53261 LENS, SIDE R.H 1

6 CY-1A8160-53270 LENS, CENTER 1

7 CY-1A7780-53300 HEADLIGHT ASSY, R.H. 1

8 CY-1A7000-53230 WIRE ASSY, LEAD 1

9 CY-198448-53320 BULB 12V45/45W 1

10 CY-1A7260-53350 SEAL, HEADLIGHT 2

11 CY-1A8160-53360 URETHANE, SIDE LENS 2

12 CY-198153-53410 SPRING, ADJUST 6

13 CY-1A7260-61250 BRACKET ASSY, L 1

14 CY-1A7260-61260 BRACKET ASSY, R 1

15 CY-198071-61890 NUT 6,SPEED 4

16 CY-198475-65030 CUSHION 8

17 CY-198475-65030 CUSHION 3

18 CY-198071-65610 NUT M5,SPEED 8

19 CY-198071-65610 NUT M5,SPEED 3

20 CY-198071-65610 NUT M5,SPEED 4

21 CY-26557-060352 SCREW 6

133

FIG. 87. FRONT LAMPS
