Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-53300 WORK LAMP KIT 1
2 CY-194180-51640 CLAMP, WIRE HARNESS 1
3 CY-1A7340-54100 WORK LAMP ASSY, SW 1
4 CY-1A7470-86270 BULB, 12V-35W 1
5 CY-22137-100000 WASHER 10, POLISHED 1
6 CY-22217-100000 SPRING WASHER 10 1
7 CY-26736-100002 NUT M10 1
180
FIG. 114. WORK LAMP (OPTIONAL)
Copyright 2007 Cub Cadet Yanmar LLC
