Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-194150-21910 PLUG 11.2 2
2 CY-22217-120000 SPRING WASHER 12 1
3 CY-22351-080018 SPRING PIN 8X18 2
4 CY-24761-020000 NIPPLE PT1/8,GREASE 2
5 CY-26013-120352 BOLT M12X 35 1
6 CY-26013-121052 BOLT M12X105 3
7 CY-26013-121152 BOLT M12X115 2
8 CY-26013-121402 BOLT M12X140 2
9 CY-26716-120002 NUT 12 1
10 CY-198240-21180 COVER 1
11 CY-26106-080162 BOLT M 8X 16 PLATED 2
63
FIG. 30. DOCKING BOLT
Copyright 2007 Cub Cadet Yanmar LLC
