REF

NO.

PART NUMBER DESCRIPTION QTY

1 CY-198220477101 GUIDE, LEVER 1

2 CY-198220-47750 STOPPER 1

3 CY-194130-47851 KNOB 1

4 CY-1A8160-62010 FENDER (M L CMP) 1

5 CY-1A8160-62020 FENDER (M R CMP) 1

6 CY-1A8160-62100 ASSY PARTS, FENDER 1

7 CY-194990-22140 NUT W/WASHER 8 8

8 CY-198220-62260 CUSHION A, RUBBER 8

9 CY-198220-62270 CUSHION B, RUBBER 8

10 CY-198220-62920 COLLAR, CUSHION 2

11 CY-22157-080000 WASHER 8 8

12 CY-26106-080302 BOLT M 8X 30 PLATED 2

13 CY-198220-62220 COLLAR 11

14 CY-198220-62410 BAR, ASSIST 2

15 CY-198220-62440 GROMMET 11

16 CY-1A8160-62600 COVER, HYDRAULIC 1

17 CY-1A8160-62640 COVER ASSY, CLUTCH 1

18 CY-1A8160-65760 LABEL, FENDER 16

19 CY-22157-060000 WASHER 6 11

20 CY-22417-200200 COTTER PIN 2.0X20 1

21 CY-26106-060122 BOLT M 6X 12 PLATED 4

22 CY-26106-060202 BOLT M 6X 20 PLATED 11

23 CY-26106-080122 BOLT M 8X 12 PLATED 4

147

FIG. 96. FENDER

Cub Cadet Yanmar Ex32002 User Manual
