Cub Cadet Yanmar Ex32002

Ex Series Ex3200
REF
NO.
PART NUMBER DESCRIPTION QTY
1 CY-1A8160-13680 BOX, FRONT GEAR UNIT 1
2 CY-1A8160-13720 BOX, FRONT GEAR L CMP 1
3 CY-1A8160-13920 STUD, BOLT 10X30 2
4 CY-1A8160-13730 BOX, FRONT GEAR R CMP 1
5 CY-1A8160-13920 STUD, BOLT 10X30 2
6 CY-1A8160-13750 CASE, FRONT GEAR 2
7 CY-1A8160-13800 SUPPORT, KING PIN CMP 1
8 CY-1A8160-13820 ARM, STEERING L.H. 1
9 CY-1A8160-13861 ARM, STEERING R.H. 1
10 CY-1A8160-13880 WASHER, 52X75X3 2
11 CY-1A8160-13890 WASHER 36X52X2 2
12 CY-1A8160-13930 NUT 10 4
13 CY-198266-28390 BOLT, 10X35 2
14 CY-198475-32660 SEAL QLNY527514.5 2
15 CY-194151-36670 PLUG PT02 2
16 CY-1E6190-54080 SLEEVE SI25X30X13 2
17 CY-22252-000520 CIRCLIP 52 2
18 CY-22351-080020 SPRING PIN 8X20 4
19 CY-23491-140002 PLUG 14 2
20 CY-24101-060094 BALL BEARING 2
21 CY-24104-063044 BALL BEARING 4
22 CY-24311-000160 O-RING 1A P-16.0 2
23 CY-24421-305208 SEAL TC30 52 08, OIL 2
24 CY-26108-100452 BOLT M10X 45 PLATED 2
49
FIG. 17. FRONT GEAR CASE
