Page #10 background imageLoading...
Page #10 background image
Table 2. J1 Connections- Input/Outputs
12 Input/Output 12
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_12
SW_12_UP
SW_12_Down
PWM12
13 Input/Output 13
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_13
SW_13_UP
SW_13_Down
PWM13
14 Input/Output 14
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_14
SW_14_UP
SW_14_Down
PWM14
15 Input/Output 15
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_15
SW_15_UP
SW_15_Down
PWM15
16 Input/Output 16
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_16
SW_16_UP
SW_16_Down
PWM16
17 Input 17
A switch to B+ digital input (pulled
low to B-). Switch this pin to B+ to
read as ON.
SW_17
SW_17_UP
SW_17_Down
18 Input 18
A switch to B+ digital input (pulled
low to B-). Switch this pin to B+ to
read as ON.
SW_18
SW_18_UP
SW_18_Down
19 Input 19
A switch to ground digital input
(pulled high to +15v). Switch this pin
to B- to read as OFF.
SW_19
SW_19_UP
SW_19_Down
20 Input 20
A switch to ground digital input
(pulled high to +15v). Switch this pin
to B- to read as OFF.
SW_20
SW_20_UP
SW_20_Down
21 Input 21
A switch to ground digital input
(pulled high to +15v). Switch this pin
to B- to read as OFF.
SW_21
SW_21_UP
SW_21_Down
22 Input 22
A switch to ground digital input
(pulled high to +15v). Switch this pin
to B- to read as OFF.
SW_22
SW_22_UP
SW_22_Down
23 B-
Can be used as a low power (<2
amp) ground reference or for the
switch inputs 12 – 22 B- reference.
24 B+
Can be used to power the system
(<2 amps) or for B+ reference for
switches, etc.
Setup_BDI ADC13_Output
KSI_Filtered
KSI_Raw
1310 Vehicle Control System Users Manual Release Rev B Page 10 of 51
