Curtis 1310 User Manual

Table 2. J1 Connections- Input/Outputs
PIN NAME DESCRIPTION
RELATED VCL
FUNCTIONS REFERENCES
1 Input/Output 1
A digital input with an open collector
high frequency PWM output. This
output also provides output current
feedback. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
Get_ADC
SW_1
SW_1_UP
SW_1_Down
PWM1
ADC15_Output
2 Input/Output 2
A digital input with an open collector
high frequency PWM output. This
output also provides output current
feedback. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
Get_ADC
SW_2
SW_2_UP
SW_2_Down
PWM2
ADC16_Output
3 Input/Output 3
A switch to B+ digital input with an
open collector high frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_3
SW_3_UP
SW_3_Down
PWM3
4 Input/Output 4
A switch to B+ digital input with an
open collector high frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_4
SW_4_UP
SW_4_Down
PWM4
5 Input/Output 5
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_5
SW_5_UP
SW_5_Down
PWM5
6 Input/Output 6
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_6
SW_6_UP
SW_6_Down
PWM6
7 Input/Output 7
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_7
SW_7_UP
SW_7_Down
PWM7
8 Input/Output 8
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_8
SW_8_UP
SW_8_Down
PWM8
9 Input/Output 9
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_9
SW_9_UP
SW_9_Down
PWM9
10 Input/Output 10
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_10
SW_10_UP
SW_10_Down
PWM10
11 Input/Output 11
A switch to B+ digital input with an
open collector low frequency PWM
output. Signal is pulled to B- when
output is on.
Put_PWM
Automate_PWM
SW_11
SW_11_UP
SW_11_Down
PWM11
1310 Vehicle Control System Users Manual Release Rev B Page 9 of 51
