3 — ADJUSTMENT OF PARAMETERS
ADJUSTMENT OF PARAMETERS
A number of controller parameters can be adjusted electronically via the op-
tional programmers: either the 1311 handheld programmer or the 1314 PC
Programming Station.
*
For a complete list of the adjustments that can be made, see Section 6:
Handheld Programmer.
CHANGING PARAMETER VALUES
To change a parameter using the programmer, enter the Program menu and scroll
through the Program menu to select the desired parameter. Press the appropri
-
ate Data Inc/Dec key (“up” or “down”) until the desired value is reached. The
parameter is now set at the desired value. All programming occurs in real time.
That is, the parameters can be changed while the vehicle is in operation.
The upper and lower limits of parameters are set at the factory. Some
parameters have dependencies on other parameters. When the programmer is
being used to adjust a parameter and a limit is reached, the display will stop
changing.
Use of the programmer is described more fully in Section 6.
CONTROLLER CLONING
The optional handheld programmer also allows you to “clone” controllers,
via options in its Functions menu. You program one controller to the desired
settings, save these settings in the programmer, and then load them into other
similar (same model number) controllers, thus creating a family of controllers
with identical settings.
*
Instructions for using the 1314 PC Programming Station
are included in that programmer’s software. In this 1207B
controller manual, only the 1311 handheld programmer is
described. However, the 1314 has all the capabilities and
features of the 1311.
