Curtis 1207B Manual
PROGRAMMER OPERATION
Menu structure
When the programmer is first plugged into the controller, it uploads informa-
tion from the controller and then displays the Main Menu:
6 — HANDHELD PROGRAMMER
You scroll up and down the Main Menu by using the up and down arrows on
the Navigation Key. A blinking square (shown here as solid black) indicates
the selected item.
You can go deeper into the Main Menu by using the right arrow of the
Navigation Key; you return to the Main Menu by using the left arrow.
Pressing the right arrow when the Program menu is selected will bring you
to the list of programmable parameters, displayed in a second column to the
right. The LCD on the programmer can show seven lines of text at a time.
Selecting a parameter (in this example, Creep Speed) and then pressing the right
arrow of the Navigation Key will display a screen with additional information,
which in this example is a bar graph.
Pro gram
Mon itor
Fau lt
Fun ctio ns
Inf orma tion
Sys tem Settings
Pro gram
EMR Rev C/L 250A
Throttle Type 2
Ramp Sha pe 30
Creep Speed 5%
EMR Rev Speed 90%
Sequencing DLY 1.0 s
To return to the list of parameters, press the left arrow. To return to the Main
Menu, press the left arrow again.
Pro gram
Creep Speed
5%
min
0
max
25
To Next Page
