Curtis 1207B Manual
PROGRAMMER MENUS
Items are listed for each menu in the order they appear in the actual menus
displayed by the handheld programmer.
Program Menu (not all items available on all controllers)
EMR Rev C/L Emergency reverse current limit
Throttle Type Throttle type
*
Ramp Shape Throttle map
Creep Speed Creep speed, as percent PWM duty cycle
EMR Rev Speed Emerg. reverse speed, as % PWM duty cycle
Sequencing DLY Sequencing delay, in seconds
Variable Plug Throttle-variable plug braking:
on (variable plug) or off (fixed plug)
High Pedal Dis High pedal disable (HPD): type †
SRO Static return to off (SRO): type ‡
Anti-Tiedown Anti-tiedown: on or off
BB Check BB wiring check: on or off
Quick Star t Quick-start throttle factor
M1 Main C/L Mode 1 main current limit
M1 Plug C/L Mode 1 plug current limit
M1 Ramp C/L Mode 1 ramp start current limit
M1 Accel Rate Mode 1 acceleration rate, in seconds
M1 Max Speed Mode 1 maximum speed, as % PWM output
M2 Main C/L Mode 2 main current limit
M2 Plug C/L Mode 2 plug current limit
M2 Ramp C/L Mode 2 ramp start current limit
M2 Accel Rate Mode 2 acceleration rate, in seconds
M2 Max Speed Mode 2 maximum speed, as % PWM output
Neut Brake C/L Neutral brake current limit
Neutral Brake Neutral brake: on or off
* Throttle types: Type 1 = 5kΩ–0
Type 2 = 0–5V, 3-wire pot, and electronic throttles
Type 3 = 0–5kΩ throttles
† HPD types: Type 0 = no HPD
Type 1 = HPD on brake input
Type 2 = HPD on KSI
‡ SRO types: Type 0 = no SRO
Type 1 = SRO on brake input
Type 2 = SRO on KSI plus brake input plus a direction input
Type 3 = SRO on KSI plus brake input plus forward input
(For more detail on these options, see Appendix A: Glossary of Features and Functions.)
6 — HANDHELD PROGRAMMER
