Curtis 1207B Manual
27
2 9 J U N E 2 0 1 2 D R A F T
Monitor Menu (not all items available on all controllers)
Throttle Throttle reading, as percent of full throttle
Batt Voltage Battery voltage
Heatsink Temp Heatsink temperature
Max Temp Maximum temperature seen
*
Min Temp Minimum temperature seen
*
Brake Input Brake switch: on/off
Speed Input Mode switch: on (Mode 1) / off (Mode 2)
EMR Rev Input Emergency reverse switch: on/off
For ward Input Forward switch: on/off
Reverse Input Reverse switch: on/off
Fwd Cont Forward contactor: on/off
Rev Cont Reverse contactor: on/off
* Maximum/minimum temperatures recorded
since the Fault History was last cleared.
Fault List
This is not a menu as such, but simply a list of the possible messages you may
see displayed in the “Fault » System Faults” menu or the “Fault » Fault History”
menu. The messages are listed here in alphabetical order.
BB Wiring Check BB wiring check failed
Contactor Driver Fault Incorrect main driver feedback signal
(when shunt function is disabled)
CONT DRVR OC Contactor driver overcurrent
Currently no faults No known faults
DIR CONT We l ded Direction contactor welded
HPD High-pedal-disable (HPD) activated
HW Failsafe Hardware failsafe activated
Low Batter y Voltage Low battery voltage (<16V)
M- Shor ted M- output fault
Missing Contactor Missing contactor
Over Voltage Overvoltage (>33V)
SRO Static-return-to-off (SRO) activated
Thermal Cutback Cutback, due to over/under temp
Throttle Fault 1 Throttle input fault
Throttle Fault 2 Throttle Type changed without cycling KSI
6 — HANDHELD PROGRAMMER
