Curtis MultiMode 1215-8 User Manual

Curtis 1214-/15-/19-8 Manual 22
PROGRAMMER MENUS
Items are listed for each menu in the order they appear in the actual menus
displayed by the handheld programmer.
Program Menu (not all items available on all controllers)
EMR REV C / L Emergency reverse current limit
THROTTLE TYPE Throttle type*
RAMP SHAPE Throttle map
CREEP SPEED Creep speed, as percent PWM duty cycle
EMR REV SPEED Emerg. reverse speed, as % PWM duty cycle
SEQUENC ING DLY Sequencing delay, in seconds
VARI ABLE PLUG Throttle-variable plug braking: on or off
HIGH PEDAL DIS High pedal disable (HPD): type†
SRO Static return to off (SRO): type‡
ANT I - T I EDOWN Anti-tiedown: on or off
QU I CK START Quick-start throttle factor
M1 MA I N C / L Mode 1 main current limit
M1 PLUG C / L Mode 1 plug current limit
M1 RAMP C / L Mode 1 ramp start current limit
M1 ACCEL RATE Mode 1 acceleration rate, in seconds
M1 MAX SPEED Mode 1 maximum speed, as % PWM output
M2 MA I N C / L Mode 2 main current limit
M2 PLUG C / L Mode 2 plug current limit
M2 RAMP C / L Mode 2 ramp start current limit
M2 ACCEL RATE Mode 2 acceleration rate, in seconds
M2 MAX SPEED Mode 2 maximum speed, as % PWM output
NEUT BRAKE C / L Neutral brake current limit
NEUTRAL BRAKE Neutral brake: on or off
(Notes are on the next page.)
6 — PROGRAMMER MENUS
6
