Curtis 1214-/15-/19-8 Manual 24
Special Program Menu
RESET ALL SETT INGS Revert to original settings
CONT SETT I NGS > PROG Save controller settings in programmer
PROG SETT I NGS > CONT Load programmer settings in controller
CLEAR DIAG HISTORY Clear diagnostic history memory
CONTRAST ADJUSTMENT Adjust display contrast
LANGUAGE SELECT ION Select displayed language
PROGRAMMER I NFO Display programmer information
CONTROL LER I NFO Display controller information
Diagnostics and Special Diagnostics “Menu”
This is not a menu as such, but simply a list of the possible messages you may see
displayed when the programmer is operating in either of the Diagnostics modes.
The messages are listed in alphabetical order for easy reference.
BB WI R I NG CHECK BB wiring check failed
CONT DRVR OC Contactor driver overcurrent
DIR CONT WELDED Direction contactor welded
HPD High-pedal-disable activated
HW FA I LSA F E Hardware failsafe activated
LOW BATTERY VOLTAGE Battery voltage too low*
M- FAULT M- output fault
MISSING CONTACTOR Missing contactor
NO KNOWN FAULTS No known faults
OVERVOLTAGE Battery voltage too high†
SRO Static-return-to-off activated
THERMAL CUTBACK Thermal cutback due to temperature
THROTTLE FAULT1 Throttle input fault
THROTTLE FAULT2 Throttle low input fault
6 — PROGRAMMER MENUS
* <16 volts (24–36V models); <21 volts (36–48V models)
† >46 volts (24–36V models); >60 volts (36–48V models)
