PRINTER ELECTRICAL SPECIFICATIONS
Power supply 24 Vdc ±10% (optional external power supply)
Medium consumption 2 A
Typical. consumption
(4)
1.5 A
Standby consumption 0.1 A
ELECTRICAL SPECIFICATIONS POWER SUPPLY code 963GE020000071
Power supply voltage from 100 Vac to 240 Vac
Frequency from 50 Hz to 60 Hz
Output 24 V, 2.5 A
Power 60 W
ENVIRONMENTAL CONDITIONS
Operating temperature from 0°C to +40°C
Relative humidity (RH) from 10% to 85% (w/o condensation)
Storage temperature from -20 °C to +70 °C
Storage relative humidity (RH) from 10% to 90% (w/o condensation)
NOTES:
(1) : Respecting the regular schedule of cleaning for the device components.
(2) : Damages caused by scratches, ESD and electromigration are excluded.
(4) : Referred to a standard CUSTOM receipt (L=10 cm, Density = 12.5% dots on).
(5) : Referred to the UL measurements.
