7.3 Alignment parameters
Referring to the front of the black mark, the value of “Black mark distance” value varies from 0mm minimum and 99.9 mm
maximum.
If the “Black mark distance” value is set to 0, the alignment point is set at the beginning of the black mark.
0
+
PRINTING DIRECTION
Alignment
point:
black mark front
Alignment
point
positive values
of “Black mark distance”
82
