In the standard model the detection of black mark and paper

direction
of paper
feed
SENSOR 1
(FIXED)
THERMAL
SIDE
In the model with mobile sensor (optional) detecting the
      
the black mark detection is performed by the mobile sensor.
direction
of paper
feed
SENSOR 1
(MOBILE, OPTIONAL)
THERMAL
SIDE
