80
EXCEL V OPERATOR MANUAL
D1025, REV H, 10/17
Guidance and Manufacturer’s Declaration: Electromagnetic Immunity
The Excel V is intended for use in the electromagnetic environment specified below. The customer or the user
of the Excel V should ensure that it is used in such environment.
Immunity Test IEC 60601 Test Level Compliance Level Electromagnetic Environment:
Guidance
Electrostatic
Discharge (ESD)
IEC61000-4-2
±6kV contact
±8kV air
±2, 4, 6kV contact
±2, 4, 8kV air
Floor should be wood, concrete, or
ceramic tile. If floors are covered with
synthetic material, the relative humidity
should be at least 30%.
Electrical fast
transient/burst
IEC61000-4-4
±2kV for power sup-
ply lines
±1kV for input/output
lines
±2kV line to ground
±1kV line to line
Mains power quality should be that of a
typical commercial or hospital
environment.
Surge
IEC61000-4-5
±1kV differential
mode
±2kV common mode
±0.5, 1kV
differential mode
±0.5, 1, 2kV
common mode
Mains power quality should be that of a
typical commercial or hospital
environment.
Voltage dips,
short
interruptions and
voltage variations
on power supply
input lines
IEC61000-4-11
<5% Ut (>95% dip in
Ut) for 0.5 cycle
40% Ut (60% dip in
Ut) for 5 cycles
70% Ut (30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in
Ut) for 5 sec.
<5% Ut (95% dip in
Ut) for 0.5 cycle
40% Ut (60% dip in
Ut) for 5 cycles
70% Ut (30% dip in
Ut) for 25 cycles
<5% Ut (>95% dip in
Ut) for 5 sec.
Mains power quality should be that of a
typical commercial or hospital
environment. If the user of the Excel V
requires continued operation during
power mains interruptions, it is
recommended that the Excel V be
powered from an uninterruptible power
supply or a battery.
Power frequency
(50/60Hz)
magnetic field
IEC 61000-4-8
3 A/m N/A
Power-frequency magnetic fields
should be at levels characteristics of a
typical location in a typical commercial
or hospital environment.
NOTE: Ut is the a.c. mains voltage prior to application of the test level.
