e) The cursor keys
SEQUENCE FORWARDS
/
PAGE
FORWARDS
key
This key allows to scroll pages of the same type.
Also allows to pass to the next page when a
series of information occupies several pages.
Eg.: ! program sequence
! production pages
! parameter pages
In
PROGRAMMING
mode also allows to
create an identical sequence (copy function) to
the previous one as long as this is the last
sequence of the program.
The incorporated LED indicates whether the
sequence is the last of the program.
PAGE BACKWARDS
key
Allows to scroll backwards through pages of
the same type.
Functions in all modes except automatic mode.
Cursor upwards, to the next accessible field.
Cursor downwards, to next accessible field.
f) Other keys
START
key
Commands:
! The displacement of the axis and auxiliary
functions.
During movement the LED lights up.
! An indexation (on option depending on the
configuration) on digital axes when this key
is first pressed after switching on the DNC.
To indicate that an index is being taken the
LED remains constantly alight, until the
indexes are received. Indexes can only be taken
in
or modes.
STOP
key
This key stops, depending on the working
mode chosen, the axes or auxiliary functions in
movement
The "Stop" LED will remain alight until we
press it a second time.
NB: No axes (or auxiliary function) movement
will be authorized unless the stop LED is off.
In this group, you will find as well all the dis-
placement keys connected to the "MANUAL"
mode.
